VH-1: A good code goes a long way!

VH-1 is a multidimensional ideal compressible hydrodynamics code written in FORTRAN, for use on desktop workstations or supercomputers. It was written by the numerical astrophysics group at the University of Virginia in 1990-1991, and is based on the description of the Lagrange-Remap version of the Piece-wise Parabolic Method (PPM) given in Colella and Woodward (J Comp Phys, 54, 174).

VH-1 can be downloaded from http://wonka.physics.ncsu.edu/pub/VH-1

Our parallel version of VH-1 using MPI is extremely simple, but it works very well and maintains the adaptability of VH-1 that has made it so successful. Our approach is to break up the 3D domain into 2D planes, with each plane computed on a different processor. Evolution in the direction across planes is computed locally on individual processors after the data is transposed across processors with a single MPI_ALLTOALL call.

VH-1 has been a key component of undergraduate research projects at NCSU:

  • John Wilson: Stream/Wind Interaction in AX Mon
  • Jeff Layton: Tidal Mass Transfer in Elliptical-Orbit Binary Stars
  • Russell Strickland: Numerical Analysis of the Dynamic Stability of Radiative Shocks
  • Mike Malinowski: Hydrodynamic Simulations of the Mass Transfer in Algol
  • Brian Marks: Evolution of Cold Shock-Bounded Slabs
  • Joel Koewer: Instability of Isothermal Stellar Wind Bowshocks
  • Rosemary Stallings: Hydrodynamic Convection in Core-Collapse Supernovae
  • Drew Norman: 3D Simulations of the NTSI
  • Grant Palmquist: QPO's and the Last Stable Orbit Around Black Holes
  • Chris Hinkle: Asymmetric Supernovae and the Radio Light Curve of SN 1987A
  • Mike Raley: Gravitational Wave Signature of Core-Collapse Supernovae
  • Rukshan Jayatilak: 3D Simulations of Bondi-Hoyle Accretion
  • Dargan Frierson: Hydrodynamic Interaction of a SNR with a Pulsar Bubble
  • Nick Stoute: X-Ray Irradiated Winds from the Inner Edge of an Accretion Disk
  • Christina Hammock: Adding Passive Magnetic Fields to VH-1
  • Brett Unks: 3D Simulations of Unsteady Radiative Shocks
  • John Stanley: Expansion of Axisymmetric Supernovae
  • Vladimir Rekovic: Supernova Remnant Evolution in a Circumstellar Bubble
  • Jason Puryear: Interaction of an Extragalactic Jet with the Galactic Disk
  • Michael DeMasi: Expansion of a Supernova Remnant Through a Cloudy Medium
  • Scott Starin: Hydrodynamic Modeling of SNR Cassiopeia A
